Sensor (input) static jam service check
Step Check Yes No
1 Check media origination.
Did the media originate from the MPF?
Go to step 2. Go to step 5.
2
Check the MPF pick roll assembly.
Is the above component free of excess wear and
contamination?
Go to step 3. Clean or replace
the MPF pick roll
assembly.
Go to Go to Go to
“MPF pick roll
assembly
removal” on
page 4-26...
3
Perform a MPF print test and check the MPF pick solenoid
for proper operation.
Does the above component operate properly?
Go to step 4. Replace the MPF
pick solenoid.
Go to “MPF pick
solenoid
assembly
removal” on
page 4-26.
4
Check the MPF lift plate assembly for damage.
Is the above component free from damage?
Go to step 5. Replace the MPF
lift plate assembly.
Go to “MPF lift
plate assembly
removal” on
page 4-25.
5
Check all the media trays for proper media installation.
Is the media properly installed in all the media trays?
Go to step 6. Remove and
properly re-install
the media.
6
Check all of the media trays and the media path for
partially fed media.
Are the media trays and the media path free from any
partially fed pieces of media?
Go to step 7. Remove any pre-
staged or jammed
media.
7
Check the sensor (input) for proper operation.
1. Enter the diagnostic mode
2. Select Base sensor test
3. Observe the line item “input”
Does the display on the operator panel, change every time
the sensing area of the above sensor is interrupted or
blocked.
Go to step 9. Go to step 8.
8
Check the above sensor for proper connection.
Is the above sensor connected properly?
Replace the
Sensor (input).
Go to “Sensor
(input) removal”
on page 4-41.
Replace the
connection.
9
Perform a print test.
Does the problem remain?
Contact next
highest level of
tech support.
Problem resolved.
Use this procedure for the following jams:
• 200.13
