Model X658 paper path rolls and sensors

Functions of main components

• Media tray assembly

• Pic arm assembly (feed)

• MPF

• Xerographics

• Transfer

• Fuser

• Drive

• Electrical components and rolls

Media tray assembly

It is necessary to adjust the media tray rear guide and media tray side guide of the media tray assembly to

match the media size.

PC cartridge

Sensor (input)

PC drum

Standard bin full actuator

and sensor (standard bin full)

Diverter

Sensor

(duplex input)

Sensor (fuser output)

Sensor (narrow media)

Pick arm

assembly

Sensor (option

pass through)
