2-130 Service Manual
7462
Sensor (input) lingering jam service check.
18
Check the sensor (input) for proper operation.
1. Enter the diagnostic mode
2. Select Base sensor test
3. Observe the line item “input”
Does the display on the operator panel, change every time
the sensing area of the above sensor is interrupted or
blocked.
The sensor is
working properly.
Go to step 20.
Go to step 19.
19
Check the above sensor for proper connection.
Is the above sensor connected properly?
Replace the
Sensor (input).
Go to “Sensor
(input) removal”
on page 4-41.
Replace the
connection.
20
Perform a print test and check the pick arm assembly.
Is the media properly picked and advanced out of the media
tray?
Go to step 21. Replace the pick
arm assembly. Go
to “Pick arm
assembly
removal” on
page 4-28.
21
Perform a print test and check the main motor assembly.
Is the media properly transported and able to reach the
sensor (input)?
Go to step 22. Replace the main
drive motor
assembly. Go to
“Main drive
motor assembly
removal” on
page 4-20.
22
Perform a print test.
Does the problem remain?
Contact next
highest level of
tech support.
Problem resolved.
Use this procedure for the following jams:
• 200.01 • 200.02 • 200.17 • 200.18 • 200.19
• 200.27 • 200.28 • 200.29 • 200.37 • 200.38
• 200.39 • 200.47 • 200.48 • 200.49 • 200.57
• 200.58 • 200.59
Step Check Yes No
1 Check the media size setup and tray guides for all media
trays.
Does the media size, in use, match the size set for all
media trays?
Go to step 2. Replace the
media, or change
the media size
setup.
2
Check the fuser unit assembly for obstructions.
Is the above component free of obstructions?
Remove
obstructions.
Go to step 3.
3
Check the fuser unit assembly for excess wear and
damage.
Is the above component free of excess wear and
damage?
Go to step 4. Replace the fuser
unit assembly.
Go to “Fuser unit
assembly
removal” on
page 4-16.
Step Check Yes No
To Next Page
