Lexmark T65 Series Service Manual

Repair information 4-101
7462
Go Back
Previous
Next
Laser cover removal (model X658)
1. Remove the ADF unit assembly . See “ADF unit assembly removal (model X658)” on page 4-80
2. Remove the scanner unit assembly. See “Scanner unit assembly removal (model X658)” on page 4-91
3. Remove the scanner controller card. See “Scanner controller card assembly removal (model X658)”
on page 4-127.
4. Remove the redrive assembly. See “Redrive assembly removal (model X658)” on page 4-99.
5. Remove the five screws (A) on the left securing the laser cover.
A
