Repair information 4-241

7462

Go Back

Offset stacker LED sensor cover removal

1. Remove the screw (A) securing the LED sensor cover to the underside of the output bin.

2. Remove the offset stacker standard output bin LED. See “Offset stacker standard output bin LED and

LED clear lens removal” on page 4-243.

3. Remove the sensor (finisher media bin present). See “Offset stacker sensor (finisher media bin

present) removal” on page 4-242.
