Repair information 4-153

7462

Go Back

High capacity input tray (HCIT) tray cover, front removal

1. Open the HCIT media tray assembly until it reaches a stop.

2. Remove the six screws (A) securing the HCIT tray cover, front to the HCIT media tray assembly.
