Lexmark T65 Series Service Manual

2-134 Service Manual
7462
Go Back
Previous
Next
Sensor (fuser output) lingering jam service check.
6
Check the above sensor for proper connection.
Is the above sensor connected properly?
Replace the fuser
unit assembly.
Go to “Fuser unit
assembly
removal” on
page 4-16.
Replace the
connection.
7
Check the aligner assembly for obstructions.
Is the above component free from obstructions?
Go to step 8. Remove
obstructions.
8
Check the transfer roll assembly for damage.
Is the above component free from damage?
Go to step 9. Replace the
transfer roll
assembly.
Go to “Transfer
roll assembly
removal” on
page 4-53.
9
Perform a print test and check the main motor assembly.
Is the media properly transported and able to reach the
sensor (fuser output)?
Go to step 10. Replace the main
drive motor
assembly.
Go to “Main drive
motor assembly
removal” on
page 4-20.
10
Perform a print test.
Does the problem remain?
Contact next
highest level of
tech support.
Problem resolved.
Use this procedure for the following jams:
• 202.01 • 202.02 • 202.07 • 202.10 • 202.11
• 202.12 • 202.26 • 202.27 • 202.32 • 202.34
• 202.35 • 202.36 • 202.37 • 202.51 • 202.52
• 202.57 • 202.59 • 202.60 • 202.61 • 202.62
• 202.76 • 202.77 • 202.82 • 202.84 • 202.85
• 202.86 • 202.87
Step Check Yes No
1 Check the media size setup and tray guides for all media
trays.
Does the media size, in use, match the size set for all media
trays?
Go to step 2. Replace the
media, or change
the media size
setup.
2
Check all the media trays for proper media installation.
Is the media properly installed in all the media trays?
Go to step 3. Remove and
properly re-install
the media.
3
Check the door assembly, rear.
Is the above component properly closed?
Go to step 4. Open then
properly close the
door assembly,
rear.
Step Check Yes No
