Diagnostic information 2-173

7462

Go Back

Check the heat roll and pressure roll.

Remove the fuser unit assembly.

CAUTION: : Allow

the fuser unit

assembly to cool

down.

Is there contamination or cracks on the heat roll and/or

pressure roll?

Replace the

fuser unit

assembly.

Go to “Fuser

unit assembly

removal” on

page 4-16.

Inspect the

machine for

obstructions in

the media path.

Step Check Yes No
