Diagnostic aids 3-73

7462

Go Back

This solenoid causes the ADF pick roll to be raised and lowered in order to properly pick the media.

Switch (ADF

closed interlock)

Sensor (Media exit)

Sensor (ADF lower

door interlock)

Sensor (ADF document set)

Sensor (ADF front registration)

Sensor (ADF rear registration)

Sensor (ADF sheet through)

Sensor (ADF top

door interlock)

Sensor (ADF media length)

Sensor (ADF media width)

ADF pick solenoid
