Media transport path

The following is a cross section of the printer and the tandem tray module, showing the main components directly

associated with the media path and transport.

Models X651, X652, X654 and X656 paper path rolls and sensors

PC cartridge

Sensor (input)

PC drum

Standard bin full actuator

and sensor (standard bin full)

Diverter

Sensor

(duplex input)

Sensor (fuser output)

Sensor (narrow media)

Pick arm

assembly

Sensor (option

pass through)
