7. Determine if the printer passes or fails the skew specifications based on the values listed on the table..
8. If the printer does not meet the skew specifications, adjust the reference edge as specified in “Alignment
assembly adjustment” on page 4-3 or adjust the printhead as specified in “Polygon printhead
mechanical registration adjustment” on page 4-2 as needed.
9. Check the registration by looking at the dots at the edges of the page. Adjust as needed.
Skew Specification
(L2-L1) (R2-R1) (T2-T1) (B2-B1)
Letter ≤1.4 mm ≤1.4 mm ≤1 mm ≤1 mm
A4 ≤1.5 mm ≤1.5 mm
Legal ≤1.8 mm ≤1.8 mm
