4-36 Service Manual

7462

Go Back

6. Detach the rear duplex guide spring (C).

7. Remove the duplex guide assembly, rear.

8. Remove the screw (D) securing the rear duplex guide handle to the assembly.

9. Remove the duplex guide assembly, rear.
