Repair information 4-135

7462

Go Back

Scanner cover, front removal (model X658)

1. Remove the scanner cover, right. See “Scanner cover, right removal (model X658)” on page 4-133.

2. Remove screw (A)

3. Slide the scanner cover, front to the right, and remove.

Replacement note: Always replace the scanner cover, front before replacing the scanner cover, right.
