Diagnostic information 2-17
7462
201.31 Sensor (narrow
media) late jam
Type 2 fuser
The expected wide media is
late reaching the sensor
(narrow media) within the
specified time.
Go to sensor (narrow media)
late jam service check.
See “Sensor (narrow media)
late jam service check.” on
page 2-136.
201.32 Sensor (fuser output)
late jam
Type 2 fuser
The media is late reaching the
sensor (fuser output) within the
specified time.
Go to sensor (fuser output) late
jam service check.
See “Sensor (fuser output)
late jam service check.” on
page 2-133.
201.50 Sensor (fuser output)
late jam
Type 1 fuser
Fuser page count has
exceeded life.
The media is late reaching the
sensor (fuser output) within the
specified time.
Go to sensor (fuser output)
service check.
See “Sensor (fuser output)
service check” on
page 2-108.
201.51 Main drive motor
assembly load error.
Type 1 fuser
Fuser page count has
exceeded life.
The main drive motor assembly
has failed or caused high
mechanical load due to paper
jam or bind.
1. Check all connections on
the main drive motor
assembly.
2. Check all connections on
the system card assembly.
3. Replace the main drive
motor assembly if problem
remains. Go to “Main drive
motor assembly removal”
on page 4-20.
201.52 Sensor (fuser output)
late jam
Type 1 fuser
Fuser page count has
exceeded life.
The media is late reaching the
sensor (fuser output) within the
specified time.
Go to sensor (fuser output) late
jam service check.
See “Sensor (fuser output)
late jam service check.” on
page 2-133.
If problem remains, a type 2
fuser can be installed.
201.54 Sensor (narrow
media) late jam
Type 1 fuser
Fuser page count has
exceeded life
The media is late reaching the
sensor (narrow media) within
the specified time.
Go to sensor (narrow media)
late jam service check.
See “Sensor (narrow media)
late jam service check.” on
page 2-136.
201.55 Operator panel door
assembly interlock
switch open failure
Type 1 fuser
Fuser page count has
exceeded life
The printer detected that the
switch (operator panel door
interlock) did not cycle prior to
printer restart.
1. Remove all media present
in media path.
2. Ensure that the operator
panel door assembly is fully
open then fully closed.
3. Check operator panel door
assembly for damage.
4. Check interlock switch (in
left operator panel hinge)
for damage.
5. Check all connections on
the system card assembly.
Error
code or
message
Error contents Description/Action Possible repair actions
