Repair information 4-207

7462

Go Back

MFP stapler assembly stapler unit assembly removal

1. Remove the right cover. See “MFP stapler assembly right cover removal” on page 4-196.

2. Remove the four cable harnesses attached to the stapler unit assembly.

3. Remove the three screws (A) securing the stapler unit assembly.

4. Remove the stapler unit assembly.
