Lexmark T65 Series Service Manual

Parts catalog 7-3
7462
Go Back
Previous
Next
Assembly 1: Covers (X651, X652, X654, and X656)
Asm-
index
Part
number
Units/
mach
Units/
FRU
Description
1 40X2169 1 1 Scanner cover plug, rear (X651)
2 40X4506 1 1 Scanner cover, rear
3 40X4508 1 1 Scanner cover, right (X651, X652, X654, and X656)
4 40X4509 1 1 Scanner support platform (X651, X652, X654, and X656)
5 40X1919 1 1 Output cover assembly (X651, X652, X654, and X656)
6 40X4331 1 1 Door assembly, rear
7 40X4470 1 1 Output bail
8 40X4417 1 1 Fuser wiper cover
9 40X1918 1 1 Laser cover assembly, 550 sheet(X651, X652, X654, and X656)
10 40X4335 1 1 Cover assembly, rear lower
11 40X4629 1 1 Connection bezel assembly, rear
12 40X1917 1 1 Side cover, right (X651, X652, X654, and X656)
13 40X1972 1 1 Inner cover, right (X651, X652, X654, and X656)
14 40X2045 1 1 Operator panel cable assembly (X651, X652, X654, and X656)
15 40X2089 1 1 MPF tray door assembly (X651, X652, X654, and X656)
16 40X2077 2 1 Counter balance spring (X651, X652, X654, and X656)
17 40X2078 2 1 Spring connector (X651, X652, X654, and X656)
18 40X4631 1 1 Operator panel door latch assembly (MFP X651, X652, X654, and X656)
19 40X4377 1 1 USB cable assembly (X651, X652, X654, and X656)
20 40X6918 1 1 Operator panel door assembly with hinges (X654 and X656)
20 40X2149 1 1 Operator panel door assembly with hinges (X651 and X652)
21 40X4000 1 1 X654de touch screen bezel
21 40X4121 1 1 X656de touch screen bezel
21 40X4123 1 1 X651de touch screen bezel
21 40X5757 1 1 X652de touch screen bezel
22 40X1971 1 1 Inner cover, left (X651, X652, X654, and X656)
23 40X1916 1 1 Side cover, left (X651, X652, X654, and X656)
24 40X4481 1 1 Access door (X651, X652, X654, and X656)
25 40X1973 1 1 Media support (X651, X652, X654, and X656)
26 40X4598 1 1 Card reader cover assembly (X651, X652, X654, and X656)
27 40X4604 1 1 Card reader assembly (5125 contact/HID)
27 40X4602 1 1 Card reader assembly (3121 contact)
27 40X4603 1 1 Card reader assembly (5121 contact/RFID)
28 40X2638 1 1 Standard output bin LED assembly (X651, X652, X654, and X656)
29 40X2643 1 1 Standard output bin LED cable assembly
30 40X4601 1 1 Card reader cable assembly (X651, X652, X654, and X656)
31 40X4505 1 1 Scanner cover, front (X651, X652, X654, and X656)
32 40X4507 1 1 Scanner cover, left (X651, X652, X654, and X656)
