Parts catalog 7-7
7462
Assembly 3: Covers 2 (X658)
Asm-
index
Part
number
Units/
mach
Units/
FRU
Description
1 40X4510 1 1 Scanner cover, rear (X658)
2 40X4511 1 1 Scanner cover, right (X658)
3 40X4513 1 1 Scanner cover, front (X658)
4 40X4516 1 1 Scanner support cover, left rear (X658)
5 40X4520 1 1 Scanner support inner cover, right (X658)
6 40X4517 1 1 Scanner support cover, right (X658)
7 40X4518 1 1 Scanner support cover, right rear (X658)
8 40X1974 1 1 Stapler access cover (X658)
9 40X4514 1 1 Scanner support cover, left front (X658)
10 40X4515 1 1 Scanner support cover, left (X658)
11 40X4519 1 1 Scanner support inner cover, left (X658)
12 40X4525 1 1 Standard output bin LED assembly
13 40X4499 1 1 Standard output bin LED cable assembly (X656)
14 40X7044 1 1 Operator panel assembly (X658)
15 40X4599 1 1 Operator panel cover with card reader slot (X658)
16 40X2018 1 1 Operator panel front cover (X658)
17 40X4602 1 1 Card reader assembly (3121 contact)
17 40X4603 1 1 Card reader assembly (5121 contact/RFID)
17 40X4604 1 1 Card reader assembly (5125 contact/HID)
18 40X4491 1 1 Operator panel bezel (X658)
19 40X4492 1 1 Operator panel cable assembly (X658)
20 40X4500 1 1‘ USB cable assembly (X658)
21 40X4600 1 1 Card reader cable assembly (X658)
22 40X4512 1 1 Scanner cover, left (X658)
