Parts catalog 7-11
7462
Assembly 5: Pick arm and media tray assemblies
Asm-
Index
Part
number
Units/
mach
Units/ kit
or pkg
Description
1 40X4459 1 1 MPF lift plate assembly (X651, X652, X654, and X656)
1 40X4425 1 1 MPF lift plate assembly with spring (X658)
2 40X6994 1 1 MPF pick solenoid assembly
3 40X1883 1 1 MPF pick roll assembly with flange and clip
4 40X4457 1 1 MPF cam gear
5 40X5786 1 1 Media tray assembly, 550 sheet (X651, X652, X654, and X656)
5 40X2164 1 1 Media tray assembly (X658)
6 40X6932 3 1 Tray size sensing actuator
7 40X4472 1 1 Switch (media size assembly)
8 40X4307 1 1 Pick arm spring
9 40X4308 1 2 Pick roll assembly (2)
10 40X4310 1 1 550 Sheet media out actuator
11 40X4305 1 1 550 Sheet pick arm assembly with spring
12 40X4313 1 1 Pick arm sensor cable assembly
