Parts catalog 7-13
7462
Assembly 6: Drive motor assembly, redrive, and duplex
Asm-
Index
Part
number
Units/
mach
Units/ kit
or pkg
Description
1 40X4467 1 1 Redrive assembly
2 40X5851 1 1 Duplex drive motor assembly
3 40X4346 1 5 Duplex assembly with 2 belts and 2 pulleys
4 40X4351 1 1 Duplex guide handle
5 40X4352 1 1 Duplex guide, rear
6 40X4353 1 1 Duplex guide spring, rear
7 40X4349 1 1 Duplex guide spring, right
8 40X4348 1 1 Duplex guide assembly, front
9 40X5551 1 1 Duplex guide spring, left
10 40X4369 1 1 Sensor (duplex input)
11 40X4345 1 1 Duplex input sensor assembly
12 40X4350 1 1 Duplex drive belt, lower
13 40X4354 1 1 Duplex drive belt, upper
14 40X4303 1 3 Alignment assembly with ground strap and adj. screw
15 40X4473 1 2 Option drive shaft with spring
16 99A0954 1 1 Bevel gear with grease packet and washer
• Bevel gear (1)
• Instruction sheet (1)
• Grease packet (1)
17 40X5749 1 1 Main drive motor assembly with option drive shaft
18 40X4386 1 1 Fuser drive release linkage
19 40X5850 1 1 Redrive motor assembly
