2.1 General Specification
The following table shows the general specification of XGT series.
No.
Item Specification
1
0 ~ 55 °C
-
2
Storage
temperature
−25 ~ +70 °C
-
3
5 ~ 95%RH (Non-condensing) -
5 ~ 95%RH (Non-condensing)
5
Vibration
resistance
Frequency Acceleration Amplitude How many times
IEC61131-2
5 ≤ f < 8.4Hz - 3.5mm
10 times each directions
(X, Y and Z)
8.4 ≤ f ≤ 150Hz
9.8 ㎨ (1G)
-
For continuous vibration
㎨
6 Shock resistance
Peak acceleration: 147 m/s
2
(15G)
Duration: 11ms
• Half-sine, 3 times each direction per each axis
IEC61131-2
7 Noise resistance
Square wave
AC: ± 1,500V
LSIS standard
Electrostatic
Voltage : 4kV (contact discharging)
IEC 61131-2,
Radiated
electromagnetic
80 ~ 1,000 MHz, 10V/m
IEC 61131-2,
IEC 61000-4-3
Fast transient
/bust noise
Segment
Power supply
Digital/analog input/output communication
IEC 61131-2,
IEC 61000-4-4
Free from corrosive gasses and excessive dust
Note
1. IEC (International Electrotechnical Commission):
An international nongovernmental organization which promotes internationally cooperated standardization in
electric/electronic field, publishes international standards and manages applicable estimation system related with.
2. Pollution degree:
An index indicating pollution degree of the operating environment which decides insulation performance of the devices.
For instance, Pollution degree 2 indicates the state generally that only non-conductive pollution occurs. However, this state
contains temporary conduction due to dew produced.
