Chapter 6 Motion Function Blocks
6.8.3 Reset (NC_Reset)
NC_Reset
NcChannelNcChannel
Execute Done
UINTUINT
BOOL BOOL
Busy BOOL
Error BOOL
ErrorID WORD
Set the NC channel to make the command.
In the rising Edge, the NC is reset.
Indicate the state of motion function block completion.
Indicate that the execution of motion function block is not completed.
Indicate whether an error occurs or not.
Output the number of error occurred while motion function block is running.
(1) This motion function block is to make the NC reset state under the NC control.
(2) If NC_Reset is executed during the automatic operation, it stops the automatic operation and changes into the reset state.
(3) The Reset state is as follows.
Contents Status
Setting Data Offset Value Hold
Parameter Hold
Various Data Program in Memory Hold
Contents in the buffer storage MDI: Hold
Other cancel
Display of Sequence Number Hold
One shot G code Cancel
Modal G code Hold
F Hold
S, T, M Hold
K (Number of repeats) Cancel
Work coordinate value Hold
