Chapter 10 CPU Function
10-25
10.4 RTC Function
The motion controller has the embedded clock (RTC) function that keeps running by battery backup even when the
power is off. The time data of the embedded RTC can be used for time management such as the system’s operating
history or failure history, etc. The RTC’s current time is updated every scan by the flags for the system’s operating
state information.
10.4.1 How to Use the RTC
(1) Reading/Setting clock data
(a) Reading the data from XG5000 and setting
1) Click『Online』-『Diagnosis』- 『motion controller information』.
2) Click the motion controller clock tab of『motion controller information』.
