6.8.11 M Code operation completed (NC_McodeComplete)
Motion Function Block
NC_McodeComplete
NcChannelNcChannel
Execute Done
UINTUINT
BOOL BOOL
Busy BOOL
Error BOOL
ErrorID WORD
Input-Output
UINT
NC channel
Set the NC channel to make the command.
Input
BOOL
Execute
Set the completion of the M Code operation on the corresponding the channel.
Output
BOOL
Done
Indicate the state of motion function block completion.
BOOL
Busy
Indicate that the execution of motion function block is not completed.
BOOL
Error
Indicate whether an error occurs or not.
WORD
ErrorID
Output the number of error occurred while motion function block is running.
(1) This motion function block makes the completion command of the M Code operation for the corresponding NC channel
under the NC control.
(2) It is the command to check the M code on the corresponding channel and set that the M code operation is completed.
