Chapter 12 SD Additional Function
Chapter 12 SD Additional Function
12.1 Overview
The motion controller has built-in additional functions using the SD card.
This chapter describes the specifications and usage of the SD additional features.
12.1.1 Characteristics
Through the motion controller’s SD additional features, you can perform the PLC update, backup, comparison, boot
operation. These functions can be executed by operating the SD CMD buttons on the PLC.
(1) SD card setting function for SD additional features
- SD card setting through XG5000
(2) Motion controller update using the SD card
- Preventing leak of the motion controller program by using password setting
- Limit update using the motion controller’s MAC address
- Motion controller’s auto reset and operation mode can be set after updating
(3) Motion controller backup using the SD card
- Motion controller’s program can be saved to the SD card without XG5000
- Motion controller’s history also can be backed up.
(4) Comparison with the motion controller using the SD card
- You can compare the motion controller’s parameters, motion data, motion controller programs, NC codes, CAM
data.
- The comparison results can be saved and checked on the SD card.
(5) Motion controller’s boot operation using the SD card
- Motion controller program can be protected by password setting.
- Limiting the boot operation using the motion controller’s MAC address
