LSIS XGT Series User Manual

Chapter 11 Datalog Function
11-103
(2) Methods on how to check the data storage processing time
To confirm whether the collected data is stored normally in the SD card, check the following contents
Checklist
Contents and Solutions
Note
Buffer
overflow
flag
Contents
Check whether the number of times when the buffer overflow occurred
in K area is 0.
If it is not 0, data collection is faster than data collection time, and thus
the data may not be stored.
Insert ‘C” string in the saved file
Solutions
For the main task cycle, increase the main task cycle, and increase the
sampling period in case of the specified cycle sampling.
Reduce the amount of data collected per sampling.
Only the necessary data is saved as a file (using the trigger storage
function).
