Chapter 2 Specification
2.2 Power Specification
The following table shows the power specifications of motion controller.
Items
Specification Remark
Input
Rated input voltage AC100V~AC240V
Input frequency 50/60Hz
Input current
0.7A or less AC100V
0.4A or less AC240V
Inrush current 120Apeak or less AC240V, Phase 90 degree
Leakage current 3mA or less
Efficiency 65% or more
Permitted momentary
power failure
10ms or less
Output
Output voltage
Voltage Output voltage ripple range current
+5V 4.90V~5.20V 4A
+24V 21.1V~26.9V 0.4A
Ripple & Noise
Voltage Ripple Noise
+5V 100mVpp or less 200mVpp or less
+24V 400mVpp or less
Protecting overcurrent
Voltage Current
+5V 4.4A or more
+24V 0.44A or more
* For protection of the power supply, you are recommended to use the power supply with the maximum of 4A fuse.
Note
1. Allowable instantaneous interruption time
It is the time to maintain the normal output voltage(normal operation) on the condition that the input voltage of
(AC110/220V) is lower than the maximum/minimum (AC85/170V).
2. Overcurrent protection
(a) When the voltage exceeding the standard is applied to the circuit of DC5V,DC24V, overcurrent protection device
interrupts the circuit and stops the system.
(b) If overcurrent occurs, after removing the causes such as shortage of current capacity, short circuit, etc., restart
the system.
3. Overvoltage protection
When the voltage exceeding the standard is applied to the circuit of DC5V, overvoltage protection device interrupts the
circuit and stops the system.
