Chapter 11 Datalog Function
11-3
11.1.3 Operation Sequence
Datalog is performed in the following sequence.
Datalog function check
Install PADT
Datalog system configuration
Wiring
Datalog parameter
Download parameter
SD memory insert
Motion controller RUN
Data log condition occur
Normal?
Finish
Start
Check error code
Check datalog
- Check specification, feature of datalog
Install XG5000 software to control motion controller
Configure the datalog system
- Check SD memory specification, and choose memory card
(Motion controller FAT 32, 32GB)
Wire power, input/output signal and controller and devices
Set logging method, sampling time, trigger condition,
storage device, output SCV file and so on
Set parameter by XG5000, download into motion controller
Turn motion controller RUN mode
No
Yes
Note
1. The SD memory should be formatted in FAT 32 format to be used for motion controller datalog function.
2. The maximum storage of SD memory supported is 32GB.
