6.3.18 Abort trigger events (MC_AbortTrigger)
Motion Function Block
MC_AbortTrigger
Axis
Axis
TriggerInput
Done
UINT
UINT
UINT
BOOL
BOOL
Execute
Busy
BOOL
Error
BOOL
ErrorID
WORD
TriggerInput USINT
Input-Output
UINT
Axis
Specify the axis to be commanded (1~32: real axis)
UINT
TriggerInput
Specify the trigger signal to be disengaged. (0: TouchProbe 1, 1: TouchProbe 2)
Input
BOOL
Execute
The trigger on standby in the relevant axis in the rising Edge is disengaged.
Output
BOOL
Done
Indicate the state of motion function block completion.
BOOL
Busy
Indicate that the execution of motion function block is not completed.
BOOL
Error
Indicate whether an error occurs or not.
WORD
ErrorID
Output the number of error occurred while motion function block is running.
(1) This motion function block is to disengage the trigger which is on standby in the relevant axis.
(2) Specify the trigger signal to be disengaged in TriggerInput. The value unable to be set causes "error 0x10E1”.
