6.5.13 Absolute positioning circular interpolation operation (MC_MoveCircularAbsolute)
Motion Function Block
MC_
MoveCircularAbsolute
Done
Execute
AxesGroup
AxesGroup
BOOLBOOL
UINT UINT
UINT
CircMode
LREAL[ ]
AuxPoint
Busy
BOOL
CommandAborted
BOOL
Error
BOOL
ErrorID
WORD
LREAL[ ]
EndPoint
Active
BOOL
UINT PathChoice
LREAL Velocity
LREAL Acceleration
LREAL Deceleration
LREAL Jerk
UINT
BufferMode
UINT
TransitionMode
LREAL TransitionParameter
Input-Output
UINT AxesGroup
Set the group to do absolute position circular interpolation operation. (1 ~ 16: Group
1 ~ Group 16)
Input
BOOL Execute
Give absolute position circular interpolation operation command to the relevant
group in the rising Edge.
UINT
CircMode
Circular interpolation method setting [0: Midpoint, 1: Central point, 2: Radius]
LREAL[ ] AuxPoint
Specify the position of auxiliary point depending on the circular interpolation
method in an absolute coordinate.
LREAL[ ]
EndPoint
Specify the end point of circular arc in an absolute coordinate.
BOOL PathChoice
Circular route selection
0: Clockwise, 1: Counterclockwise
LREAL
Velocity
Specify the maximum speed of the route. [u/s]
LREAL
Acceleration
Specify the maximum acceleration. [u/s
2
]
LREAL
Deceleration
Specify the maximum deceleration. [u/s
2
]
LREAL
Jerk
Specify the change rate of acceleration/deceleration. [u/s
3
]
UINT BufferMode
Specify the sequential operation setting of motion function block.
(Refer to 6.1.4.BufferMode)
UINT
TransitionMode
Unused
LREAL
TransitionParameter
Unused
