LSIS XGT Series User Manual

Chapter 6 Motion Function Blocks
6-164
6.7.6 Circular interpolation operation for absolute position of coordinate system
(MC_MoveCircularAbsolute2D)
Motion Function Block
MC_MoveCircularAbsolute2D
Done
Execute
AxesGroup
AxesGroup
BOOLBOOL
UINT UINT
UINT CircMode
LREAL[ ] AuxPoint
Busy
BOOL
CommandAborted
BOOL
Error
BOOL
ErrorID
WORD
LREAL[ ] EndPoint
Active
BOOL
UINT PathChoice
LREAL Velocity
LREAL Acceleration
LREAL Deceleration
LREAL Jerk
UINT BufferMode
UINT TransitionMode
LREAL TransitionParameter
UINT CoordSystem
Input-Output
UINT AxesGroup
Set the axes group to set the absolute position circular interpolation.(1 ~ 16 : Group
1 ~ Group 16)
Input
BOOL
Execute
Give the circular interpolation command on the axes group in the rising Edge.
UINT CircMode
The way to set the circular interpolation [0: Middle point
Aux point, 1: Center point, 2: Radius]
LREAL[ ] AuxPoint
The auxiliary point position for circular interpolation is designated as an absolute
coordinate.
LREAL[ ]
EndPoint
Set the circular end point as an absolute coordinate.
BOOL PathChoice
Set the circular path.
0: clockwise direction, 1: counter-clockwise direction
LREAL
Velocity
Set the maximum velocity of the path.. [u/s]
LREAL
Acceleration
Set the maximum acceleration. [u/s
2
]
LREAL
Deceleration
Set the minimum deceleration. [u/s
2
]
LREAL
Jerk
Set the maximum acc/dec jerk. [u/s
3
]
UINT
CoordSystem
Set the coordinate system’s type. (1:MCS 2:PCS)
UINT BufferMode
Specify the sequential operation setting of motion function block.
(Refer to 6.1.4.BufferMode)
UINT
TransitionMode
Unused
LREAL
TransitionParameter
Unused
