Chapter 9 NC Control Function
9-14
Category
Program instruction
Function
Position
command
X, Y, Z, A, B, C, U, V, W, S
Specify the location of the axis
I, J, K
Rotating central point coordinate of each axis for circular
interpolation
Speed
command
F
Feed rate command
Dwell time
X
Specify the dwelling time
Other
instruction
N
Specify the Statement Number
P
Specify the call number of the subprogram
IF
Conditional branch instruction and conditional operation
GOTO
Branch instruction
WHILE, DO
Execute a certain program repetitively
END
End of loop
%, ;
Comment processing command
LE, GE, EQ, LT, GT, NE
Compare instruction
AND, OR, XOR, +, -, *, /
Operation instruction
=
Assignment operator
SIN, COS, TAN, ATAN,
SQRT, ABS, ROUND,
AND, OR, RIX, FUP
Mathematical operation function
9.3.3 Description of the NC Command
(1) G code
The G code defines the types of the commands such as feed and machining method of each axis during machining,
and it is the command to carry out mechanical drive and operation of the NC program, etc.
There are two types of G code as shown below.
Category
Description
One-shot G code instruction
G code instruction that is valid only in the block to which the G code is
commanded
Modal G code instruction
G code instruction that is valid until it is released by another command from
the block to which the G code is commanded
