Chapter 11 Datalog Function
(c) Completion Phrase
_SD_FmtDone(%KX8369) Bit turns ON when formatting is complete. In this case, the following completion
window appears.
If formatting failed, an error window appears along with the relevant code.
SD Detachment File System Damage
11.7.3 Diagnosis Function
Datalog provides SD memory diagnosis function.
SD memories that do not comply with the following cannot be used. Datalog function will not be executed when such
memories are connected.
(1) FAT32 File System Diagnosis
☞ The memory should be formatted using the FAT32 format, to allow for file saving.
Files will not be saved if it is formatted using other formats.
Caution
Since sudden power off may cause file system / file damage or saving of abnormal data.
Therefore, make sure to execute STOP flag or push the SD CMD button for 2 second when trying to stop
datalog function, so as to ensure normal data saving.
