Select item PRINTOUT MODE to chose the mode the data are printed: The following options appear:
→ AT CYCLE END +
STEP BY STEP ↑
EXIT ↓
-
Select AT CYCLE END to print the report al the end of the cycle.
Select STEP BY STEP to print the data at each phase of the cycle, as result in the normal printout (see Printed report examples).
e The print of the Vacuum and Helix Test report is carried out only in mode “At Cycle End”.
Activate NR. COPIES to set the number of copies of the cycle report to print at the end of the program. The following text appears:
COPIES: XX
+/- to set
↵ to enter
↑ to exit
Set the number of copies desired (up to a maximum
of 5). Confirm with the ↵ key.
e In STEP BY STEP mode is not possible more report copies.
On the other hand, the selection PRINT LAST reprints the report for the last cycle executed (whether it terminated correctly or was
interrupted by an alarm). The following screen appears:
→ NORMAL PRINT +
EXTENDED PRINT ↑
EXIT ↓
-
The NORMAL PRINT command activates normal printing (that with salient cycle data produced at the end of a correctly executed cycle),
while EXTENDED PRINT activates complete printing (including all the data typical of a cycle interrupted by an alarm).
