This function allows you to manually focus on any
position by operating the focus ring on the lens.
3
1
2
Near
O
Focus ring
1
2
3
MF (Manual
focus)
S-AFJ
The camera focuses in S-AF mode. You can adjust the focus position by
operating the focus ring on the lens.
C-AF+TR (AF
tracking)
Press the shutter button halfway or press the AF-ON button to focus; the
camera then tracks and maintains focus on the current subject while the button
is held in position.
In movie recording mode, the camera continues AF tracking even if you release
the button before you start recording. To stop it, press the OK button.
When you start recording a movie while the camera is tracking the subject, it will
continue tracking.
AF tracking always operates during recording.
During AF tracking, a white frame is displayed on the subject being tracked.
If the tracked subject is lost, the frame will be displayed in gray. Release
the button and then frame the subject again and press the shutter button
halfway or press the AF-ON button.
If [On2] is selected for [AF Area Pointer], AF targets will appear at the areas
in focus instead a white frame.
When using AF tracking (P.106), [bAll] cannot be selected for AF target
mode.
Tracking AF cannot be used with:
keystone compensation, High Res Shot, focus bracketing, focus stacking,
interval-timer photography, HDR photography, live ND shooting, live GND
shooting, fisheye compensation
Pre J (Preset
MF)
The camera automatically focuses on the preset focus point when shooting.
RAF (Starry
Sky AF)
(only during
shooting)
Choose this mode for pictures of stars in the night sky. Press the AF-ON button
to focus on the stars. g“Using Starry Sky AF” (P.102)
101
Choosing a focus mode (KAF Mode / nAF
Mode)
B
C
C
-
