Page #105 background imageLoading...
Page #105 background image
Use the multi selector to position the AF target.
1
Multi selector
1
The AF target is displayed at the start of the operation.
To select the center AF target, press the multi selector or
press and hold the OK button.
SmallSmall
Choosing a Focus Target (AF Target Point)
P A S M B n
The frame showing the location of the focus point is referred to as the “AF target”. You can position the
target over your subject. At default settings, the multi selector is used to position the AF target.
You can choose whether AF target selection “wraps around” the edges of the display (P.141).
Release the shutter.
The AF target selection display will clear from the monitor when the shutter button is
pressed halfway.
The AF frame is displayed in the position of the selected AF target.
You can reposition the AF target during focusing when [C-AF] or [C-AFJ] is selected in still
photography mode.
You can also reposition the AF target during movie recording.
The size and number of the AF target changes depending on shooting settings.
When [On] is selected for [AF Targeting Pad] (P.143), you can reposition the AF target using
monitor touch controls while framing your subject in the viewfinder.
105
Choosing a Focus Target (AF Target Point)
1.
B
2.
B
B
B
B

Table of Contents

Other manuals for OM SYSTEM OM-1 Mark II

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the OM SYSTEM OM-1 Mark II and is the answer not in the manual?

OM SYSTEM OM-1 Mark II Specifications

General IconGeneral
Camera TypeMirrorless
Sensor Resolution20.4MP
Image ProcessorTruePic X
ConnectivityWi-Fi, Bluetooth, USB-C, HDMI
Body ConstructionMagnesium Alloy
Dimensions134.8 x 91.6 x 72.7 mm
Sensor SizeFour Thirds
ISO RangeISO 200-102400 (expandable to ISO 80-102400)
Image Stabilization5-axis in-body
Autofocus System1053-Point Hybrid Autofocus
Viewfinder TypeElectronic (EVF)
Viewfinder Resolution5.76 million dots
Viewfinder Magnification1.65x (35mm equivalent)
Rear Screen3.0" vari-angle touchscreen
Rear Screen Resolution1.62 million dots
Video Recording4K UHD at 60p/50p/30p/25p/24p
Video FormatMOV
Audio RecordingStereo, external mic input
Storage MediaDual SD Card Slots (UHS-II)
BatteryBLX-1 Lithium-Ion Battery
Weight599 g (with battery and memory card)
Battery LifeApprox. 520 shots (CIPA standard)
Shutter Speed1/8000 to 60 sec
Weather SealingYes (IP53 rated)
