OM SYSTEM OM-1 Mark II User Manual

Monitor Brightness and Hue (Monitor Adjust)
P A S M B n
Adjust monitor color temperature and brightness. This option applies in both still photography and
movie modes.
Menu
MENU U e U 3. Monitor/Sound/Connection U Monitor Adjust
o (Color
temperature)
Adjust color temperature.
Use the front dial or HI to adjust the “amber–blue” axis. Moving the pointer
(0) closer to A adds a red cast and moving it closer to B adds a blue cast.
Use the rear dial or FG to adjust the “green–magenta” axis. Moving the
pointer (0) closer to G adds a green cast and moving it closer to M adds a
magenta cast.
p (Brightness)
Adjust brightness. Select an option using FG.
[-7] – [±0] – [+7]
Press the INFO button to switch between color temperature and brightness and set each item.
You can reset the setting by pressing and holding the OK button.
In B mode, the monitor uses the brightness selected in [Bulb/Time Monitor]. g“Configuring
BULB/TIME/COMP Settings (BULB/TIME/COMP Settings)” (P.269)
400
Monitor Brightness and Hue (Monitor Adjust)

OM SYSTEM OM-1 Mark II Specifications

General

Camera Type	Mirrorless
Sensor Resolution	20.4MP
Image Processor	TruePic X
Connectivity	Wi-Fi, Bluetooth, USB-C, HDMI
Body Construction	Magnesium Alloy
Dimensions	134.8 x 91.6 x 72.7 mm
Sensor Size	Four Thirds
ISO Range	ISO 200-102400 (expandable to ISO 80-102400)
Image Stabilization	5-axis in-body
Autofocus System	1053-Point Hybrid Autofocus
Viewfinder Type	Electronic (EVF)
Viewfinder Resolution	5.76 million dots
Viewfinder Magnification	1.65x (35mm equivalent)
Rear Screen	3.0" vari-angle touchscreen
Rear Screen Resolution	1.62 million dots
Video Recording	4K UHD at 60p/50p/30p/25p/24p
Video Format	MOV
Audio Recording	Stereo, external mic input
Storage Media	Dual SD Card Slots (UHS-II)
Battery	BLX-1 Lithium-Ion Battery
Weight	599 g (with battery and memory card)
Battery Life	Approx. 520 shots (CIPA standard)
Shutter Speed	1/8000 to 60 sec
Weather Sealing	Yes (IP53 rated)
