OM SYSTEM OM-1 Mark II User Manual

AF/MF MF
1
2 1 5 3 mm0.5
5.6 8 11 16
5.681116
AF/MF
2 1 5 3 mm0.5
5.6 8 11 16
5.681116
MF
2
MF Clutch Lenses
The “MF clutch” (manual focus clutch) mechanism on MF clutch lenses can be used to switch between
auto and manual focus simply by repositioning the focus ring.
Check the position of the MF clutch before shooting.
Sliding the focus ring to the AF/MF position at the end of the lens selects autofocus, while sliding
it to the MF position closer to the camera body selects manual focus, regardless of the focus mode
chosen with the camera.
Focus Ring
Focus distances visible
Selecting [Inoperative] for [MF Clutch] (P.149) disables manual focus even when the MF clutch
is in the MF position.
475
MF Clutch Lenses
1
2
C

OM SYSTEM OM-1 Mark II Specifications

General

Camera Type	Mirrorless
Sensor Resolution	20.4MP
Image Processor	TruePic X
Connectivity	Wi-Fi, Bluetooth, USB-C, HDMI
Body Construction	Magnesium Alloy
Dimensions	134.8 x 91.6 x 72.7 mm
Sensor Size	Four Thirds
ISO Range	ISO 200-102400 (expandable to ISO 80-102400)
Image Stabilization	5-axis in-body
Autofocus System	1053-Point Hybrid Autofocus
Viewfinder Type	Electronic (EVF)
Viewfinder Resolution	5.76 million dots
Viewfinder Magnification	1.65x (35mm equivalent)
Rear Screen	3.0" vari-angle touchscreen
Rear Screen Resolution	1.62 million dots
Video Recording	4K UHD at 60p/50p/30p/25p/24p
Video Format	MOV
Audio Recording	Stereo, external mic input
Storage Media	Dual SD Card Slots (UHS-II)
Battery	BLX-1 Lithium-Ion Battery
Weight	599 g (with battery and memory card)
Battery Life	Approx. 520 shots (CIPA standard)
Shutter Speed	1/8000 to 60 sec
Weather Sealing	Yes (IP53 rated)
