OM SYSTEM OM-1 Mark II User Manual

Available Roles
“K only”: This role is only available in the [KButton Function] menu.
“n only”: This role is only available in the [nButton Function] menu.
The options available vary from button to button.
Role Function
RREC
(movie recording)
The control functions as a movie-record button. Press to start or stop
recording.
Preview (z)
(K only)
Stop aperture down to the selected value. This lets you preview depth
of field. Aperture stops down to the currently-selected value while the
button is pressed. Preview options can be selected using [zLock] (P.360).
G
(One-touch white
balance)
Measure a value for one-touch white balance (P.231).
To measure white balance during still photography, frame a reference
object (a piece of white paper or the like) in the display, then press and
hold the control and press the shutter button. A list of one-touch white
balance options will be displayed, from which you can choose the location
to which the new value will be saved.
To measure white balance during movie recording, frame a reference
object (a piece of white paper or the like) in the display and press the
button. A list of one-touch white balance options will be displayed, from
which you can choose the location to which the new value will be saved.
AF Area Select (Y)
(AF Area Select)
Configure AF Target Mode (P.106) and AF Target Point (P.105). Press the
control to view the AF target selection display.
Use the front or rear dial to choose AF target mode and the multi selector
or arrow pad to position the AF target.
You can choose the controls used for this operation. g“AF Target
Selection (YSelect Screen Settings)” (P.140)
YHome (YHP)
(AF home position)
(K only)
Recall previously-saved [AF Target Mode], and [AF Target Point] “home
position” settings. Home position settings are saved using [Y Set
Home] (P.138).
You can save separate home positions for landscape and portrait
orientations. g“Matching AF Target Selection to Camera Orientation
(KOrientation Linked Y)” (P.136)
336
Changing the roles of buttons (Button Settings)
B
B
B

OM SYSTEM OM-1 Mark II Specifications

General

Camera Type	Mirrorless
Sensor Resolution	20.4MP
Image Processor	TruePic X
Connectivity	Wi-Fi, Bluetooth, USB-C, HDMI
Body Construction	Magnesium Alloy
Dimensions	134.8 x 91.6 x 72.7 mm
Sensor Size	Four Thirds
ISO Range	ISO 200-102400 (expandable to ISO 80-102400)
Image Stabilization	5-axis in-body
Autofocus System	1053-Point Hybrid Autofocus
Viewfinder Type	Electronic (EVF)
Viewfinder Resolution	5.76 million dots
Viewfinder Magnification	1.65x (35mm equivalent)
Rear Screen	3.0" vari-angle touchscreen
Rear Screen Resolution	1.62 million dots
Video Recording	4K UHD at 60p/50p/30p/25p/24p
Video Format	MOV
Audio Recording	Stereo, external mic input
Storage Media	Dual SD Card Slots (UHS-II)
Battery	BLX-1 Lithium-Ion Battery
Weight	599 g (with battery and memory card)
Battery Life	Approx. 520 shots (CIPA standard)
Shutter Speed	1/8000 to 60 sec
Weather Sealing	Yes (IP53 rated)
