Page #285 background imageLoading...
Page #285 background image
HDMI Output (nHDMI Output)
P A S M B n
Adjust settings for output to HDMI devices. Options are available for controlling HDMI recorders from
the camera or adding time codes for use during movie editing.
Menu
MENU U n U 5. Sound Recording/Connection U nHDMI Output
Output
Mode
[Monitor]: The HDMI device functions as an external monitor. The camera outputs
both images and indicators to the display.Output settings can be adjusted using the
[HDMI Settings] option (P.404).
[Record]: When live view is displayed in movie mode, the HDMI device functions as an
external recorder.Only images are output to the device. Frame size and sound settings
are adjusted using camera controls.
[RAW]: When live view is displayed in movie mode, images are output to the HDMI
device in RAW format. Images are not recorded on the card in the camera. Frame size
and sound settings are adjusted using camera controls.
REC Bit
The camera and the external device start and stop recording at the same time.
This option is only available with compatible devices.
[Off]: Does not use this function.
[On]: Controls the external device.
Time
Code
Output time codes to the external device. Time code settings can be adjusted using
[Time Code Settings] (P.284).
[Off]: Does not output time codes to the external device.
[On]: Output time codes to the external device.
285
