OM SYSTEM OM-1 Mark II User Manual

AF Target Selection (YSelect Screen
Settings)
P A S M B n
Choose the roles played by the front and rear dials or arrow pad during AF target selection. The
controls used can be selected according to how the camera is used or personal taste.
Menu
MENU U AF U 6. AF Target Settings & Operations U Y Select Screen Settings
w dial
Assign roles to the front and rear dials.
[Off]: None.
[tPos]: Position the AF target (P.105).
[YMode]: Choose the AF target mode (e.g., bAll, oSmall) (P.106).
d button
Assign roles to FGHI.
[Off]: None.
[tPos]: Position the AF target (P.105).
[YMode]: Choose the AF target mode (e.g., bAll, oSmall) (P.106).
140
AF Target Selection (YSelect Screen Settings)

OM SYSTEM OM-1 Mark II Specifications

General

Camera Type	Mirrorless
Sensor Resolution	20.4MP
Image Processor	TruePic X
Connectivity	Wi-Fi, Bluetooth, USB-C, HDMI
Body Construction	Magnesium Alloy
Dimensions	134.8 x 91.6 x 72.7 mm
Sensor Size	Four Thirds
ISO Range	ISO 200-102400 (expandable to ISO 80-102400)
Image Stabilization	5-axis in-body
Autofocus System	1053-Point Hybrid Autofocus
Viewfinder Type	Electronic (EVF)
Viewfinder Resolution	5.76 million dots
Viewfinder Magnification	1.65x (35mm equivalent)
Rear Screen	3.0" vari-angle touchscreen
Rear Screen Resolution	1.62 million dots
Video Recording	4K UHD at 60p/50p/30p/25p/24p
Video Format	MOV
Audio Recording	Stereo, external mic input
Storage Media	Dual SD Card Slots (UHS-II)
Battery	BLX-1 Lithium-Ion Battery
Weight	599 g (with battery and memory card)
Battery Life	Approx. 520 shots (CIPA standard)
Shutter Speed	1/8000 to 60 sec
Weather Sealing	Yes (IP53 rated)
