OM SYSTEM OM-1 Mark II User Manual

Viewfinder Brightness and Hue (EVF Adjust)
P A S M B n
Adjust viewfinder brightness and hue. The display switches to the viewfinder while these settings are
being adjusted.
Menu
MENU U e U 3. Monitor/Sound/Connection U EVF Adjust
o (Color
temperature)
Adjust color temperature.
Use the front dial or HI to adjust the “amber–blue” axis. Moving the pointer
(0) closer to A adds a red cast and moving it closer to B adds a blue cast.
Use the rear dial or FG to adjust the “green–magenta” axis. Moving the
pointer (0) closer to G adds a green cast and moving it closer to M adds a
magenta cast.
p (Brightness)
[EVF Auto Luminance Off] / [EVF Auto Luminance On]: Viewfinder
brightness and indicator contrast adapt automatically to ambient lighting
conditions. Change the setting using HI.
[p]: Adjust brightness. Select an option using FG.
[-7] – [±0] – [+7]
Brightness cannot be changed when [EVF Auto Luminance On] is selected.
Press the INFO button to switch between color temperature and brightness and set each item.
You can reset the setting by pressing and holding the OK button.
401
Viewfinder Brightness and Hue (EVF Adjust)
C

OM SYSTEM OM-1 Mark II Specifications

General

Camera Type	Mirrorless
Sensor Resolution	20.4MP
Image Processor	TruePic X
Connectivity	Wi-Fi, Bluetooth, USB-C, HDMI
Body Construction	Magnesium Alloy
Dimensions	134.8 x 91.6 x 72.7 mm
Sensor Size	Four Thirds
ISO Range	ISO 200-102400 (expandable to ISO 80-102400)
Image Stabilization	5-axis in-body
Autofocus System	1053-Point Hybrid Autofocus
Viewfinder Type	Electronic (EVF)
Viewfinder Resolution	5.76 million dots
Viewfinder Magnification	1.65x (35mm equivalent)
Rear Screen	3.0" vari-angle touchscreen
Rear Screen Resolution	1.62 million dots
Video Recording	4K UHD at 60p/50p/30p/25p/24p
Video Format	MOV
Audio Recording	Stereo, external mic input
Storage Media	Dual SD Card Slots (UHS-II)
Battery	BLX-1 Lithium-Ion Battery
Weight	599 g (with battery and memory card)
Battery Life	Approx. 520 shots (CIPA standard)
Shutter Speed	1/8000 to 60 sec
Weather Sealing	Yes (IP53 rated)
