OM SYSTEM OM-1 Mark II User Manual

You can configure the camera to display the motion of the camera
and the boundaries of motions that can be corrected by the image
stabilizer when the shutter button is pressed halfway and during
exposure. This is useful when you want to reduce camera motion
during long exposure with the camera held by hand.
1
10231023
P
1 / 250
P
1 / F 250 5.65.6
1
1
[
1
:
02
:
03
][
1
:
02
:
03
]
FF 60p60p L
-
8L
-
8
S
-
AFS
-
AF
33
200200
L
1
4K
ISO
Auto
ISO
Auto
F
00
+
-
0.00.0
100 % 100 %
1 2 3
The boundaries of motions
that can be corrected by the
image stabilizer (gray)
Camera motion (horizontal/
vertical)
Camera motion (roll)
1
2
3
Displaying camera motion on the monitor
(Handheld Assist)
P A S M B n
Menu
MENU U a U 8. Image Stabilizer U Handheld Assist
Off Camera motion is not displayed on the monitor.
On
Camera motion is displayed on the monitor when the shutter button is pressed halfway and
during exposure.
There is no guarantee that the picture will be without blurs, even if the camera motion indicator
stays within the gray frame.
Camera motion cannot be displayed correctly when the camera is close to the subject.
Camera motion is not displayed if [KImage Stabilizer] is set to [Off] or if you are using third-
party lenses, with which only the lens image stabilizer operates.
If [6Image Stabilizer] is set to [Off], camera motion is only displayed during exposure.
209
Displaying camera motion on the monitor
(Handheld Assist)
C
C
C
C

OM SYSTEM OM-1 Mark II Specifications

General

Camera Type	Mirrorless
Sensor Resolution	20.4MP
Image Processor	TruePic X
Connectivity	Wi-Fi, Bluetooth, USB-C, HDMI
Body Construction	Magnesium Alloy
Dimensions	134.8 x 91.6 x 72.7 mm
Sensor Size	Four Thirds
ISO Range	ISO 200-102400 (expandable to ISO 80-102400)
Image Stabilization	5-axis in-body
Autofocus System	1053-Point Hybrid Autofocus
Viewfinder Type	Electronic (EVF)
Viewfinder Resolution	5.76 million dots
Viewfinder Magnification	1.65x (35mm equivalent)
Rear Screen	3.0" vari-angle touchscreen
Rear Screen Resolution	1.62 million dots
Video Recording	4K UHD at 60p/50p/30p/25p/24p
Video Format	MOV
Audio Recording	Stereo, external mic input
Storage Media	Dual SD Card Slots (UHS-II)
Battery	BLX-1 Lithium-Ion Battery
Weight	599 g (with battery and memory card)
Battery Life	Approx. 520 shots (CIPA standard)
Shutter Speed	1/8000 to 60 sec
Weather Sealing	Yes (IP53 rated)
