OM SYSTEM OM-1 Mark II User Manual

USB-AC adapter (supplied)
AC outlet
USB cable (supplied)
1
2
3
USB connector
Battery charge lamp
4
5
The battery charge lamp lights during
charging. Charging with the camera turned
off takes about 2 hours 30 minutes. The
lamp goes out as the batteries reach full
charge. Remove the USB cable from the
camera.
Charging the battery using the USB-AC
adapter
The battery will not be fully charged at the time of purchase. Charge the battery before use.
Check that the battery is in the camera, and connect the USB cable and USB-AC adapter.
When attaching the USB cable, use an optional cable protector and cable clip to prevent
damage to the connectors and disconnection. g“Cable Clip (CC-1) / Cable Protector
(CP-2)” (P.486)
Refrain from using anything other than the USB cable (CB-USB13) supplied with the camera
or sold separately.
2
2
3
1
1
4
5
3
1
2
2
1
If a charging error occurs, the battery charge lamp will blink. Disconnect and reconnect the
USB cable.
30
Charging the battery using the USB-AC adapter
C
1.
C
C

OM SYSTEM OM-1 Mark II Specifications

General

Camera Type	Mirrorless
Sensor Resolution	20.4MP
Image Processor	TruePic X
Connectivity	Wi-Fi, Bluetooth, USB-C, HDMI
Body Construction	Magnesium Alloy
Dimensions	134.8 x 91.6 x 72.7 mm
Sensor Size	Four Thirds
ISO Range	ISO 200-102400 (expandable to ISO 80-102400)
Image Stabilization	5-axis in-body
Autofocus System	1053-Point Hybrid Autofocus
Viewfinder Type	Electronic (EVF)
Viewfinder Resolution	5.76 million dots
Viewfinder Magnification	1.65x (35mm equivalent)
Rear Screen	3.0" vari-angle touchscreen
Rear Screen Resolution	1.62 million dots
Video Recording	4K UHD at 60p/50p/30p/25p/24p
Video Format	MOV
Audio Recording	Stereo, external mic input
Storage Media	Dual SD Card Slots (UHS-II)
Battery	BLX-1 Lithium-Ion Battery
Weight	599 g (with battery and memory card)
Battery Life	Approx. 520 shots (CIPA standard)
Shutter Speed	1/8000 to 60 sec
Weather Sealing	Yes (IP53 rated)
