OM SYSTEM OM-1 Mark II User Manual

Choosing a Flash Mode (Flash Mode)
P A S M B n
Button
gYA Button UFGl
Super control panel
OK U Flash Mode
Flash Modes
Flash modes that are displayed vary depending on the configuration of [Flash Mode Settings] (P.183).
A
Fill In
Enable the flash.
Shutter speed can be set to values between that selected for [A
Slow Limit] (P.187) and [A X-Sync.] (P.186).
B
Flash Off
Disable the flash.
The flash will not fire even if the unit is on.
ASlow
Slow
Slow shutter speeds are used to capture both the main subject and the
background.
Shutter speed is set according to the exposure value metered by
the camera and is not restricted by the option selected for [A Slow
Limit].
A Manual
Manual
The flash fires at the selected level.
Appears only when the FL-LM3 is attached.
179
Choosing a Flash Mode (Flash Mode)
C
C
C

OM SYSTEM OM-1 Mark II Specifications

General

Camera Type	Mirrorless
Sensor Resolution	20.4MP
Image Processor	TruePic X
Connectivity	Wi-Fi, Bluetooth, USB-C, HDMI
Body Construction	Magnesium Alloy
Dimensions	134.8 x 91.6 x 72.7 mm
Sensor Size	Four Thirds
ISO Range	ISO 200-102400 (expandable to ISO 80-102400)
Image Stabilization	5-axis in-body
Autofocus System	1053-Point Hybrid Autofocus
Viewfinder Type	Electronic (EVF)
Viewfinder Resolution	5.76 million dots
Viewfinder Magnification	1.65x (35mm equivalent)
Rear Screen	3.0" vari-angle touchscreen
Rear Screen Resolution	1.62 million dots
Video Recording	4K UHD at 60p/50p/30p/25p/24p
Video Format	MOV
Audio Recording	Stereo, external mic input
Storage Media	Dual SD Card Slots (UHS-II)
Battery	BLX-1 Lithium-Ion Battery
Weight	599 g (with battery and memory card)
Battery Life	Approx. 520 shots (CIPA standard)
Shutter Speed	1/8000 to 60 sec
Weather Sealing	Yes (IP53 rated)
