If the connection fails, the camera will display a message to
that effect, followed by the options shown in Step 3. Remove
and reinsert the memory card.
Connection failed
100
%
100
%
Choosing a Network from a List (Connect from
z List)
The camera will search for available networks and display them in a list from which you can choose the
network to which you wish to connect.
Menu
MENU U e U 4. Wi-Fi/Bluetooth U Wi-Fi Connection
Highlight [PC Connection] using the FG buttons and press the OK button.
[PC Connection] options will be displayed.
Highlight [Connect from z List] using the FG buttons and press the OK button.
A list of available networks will be displayed.
Highlight the desired network using the FG buttons and press the OK button.
If the network is password-protected, you will be prompted to enter a password. Enter the
password and press the OK button.
Press the I button to display [Detail Settings] for the highlighted network. You can enter
an IP address and adjust other settings manually.
Press the R button to repeat the search and update the network list.
If the camera is able to connect, the network will be displayed with a check (P) next to the
network name.
Password-protected networks are indicated by a 2 icon.
If the camera has been paired with more than one computer, you will be prompted to choose
a computer before the network is displayed. Highlight the desired computer using the FG
buttons and press the OK button.
The camera can be used only with the selected computer. To select a different computer, you
must first terminate the current connection.
447
Adjusting Wi-Fi Settings (Wi-Fi Connection)
1.
2.
3.
4.
