If the camera is able to connect, the network will be displayed
with a check (P) next to the network name.
PC Connection
Connect by WPS
Connect manually
SSID_001
2A
OK
MENU
Enabling Camera Wi-Fi
Before connecting to a network via Wi-Fi, you will need to enable Wi-Fi on the camera. If [Airplane
Mode] (P.424) is set to [On], set it to [Off].
Connecting via WPS (Connect by WPS)
Connect using the WPS feature on the router or access point.
Menu
MENU U e U 4. Wi-Fi/Bluetooth U Wi-Fi Connection
Highlight [PC Connection] using the FG buttons and press the OK button.
[PC Connection] options will be displayed.
Highlight [Connect by WPS] using the FG buttons and press the OK button.
Highlight an option using the FG buttons and press the OK button.
If you selected [PBC Method], press the WPS button on the router or access point.
Press the camera OK button to start the connection.
Some time may be required for connection after the button is pressed.
If you selected [PIN Method], the camera will display a PIN; enter it on the router or access
point. Press the camera OK button when the router is ready to connect.
If the camera has been paired with more than one computer, you will be prompted to choose
a computer before the network is displayed. Highlight the desired computer using the FG
buttons and press the OK button.
The camera can be used only with the selected computer. To select a different computer, you
must first terminate the current connection.
442
Adjusting Wi-Fi Settings (Wi-Fi Connection)
1.
2.
3.
4.

Table of Contents

Other manuals for OM SYSTEM OM-1 Mark II

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the OM SYSTEM OM-1 Mark II and is the answer not in the manual?

OM SYSTEM OM-1 Mark II Specifications

General IconGeneral
Camera TypeMirrorless
Sensor Resolution20.4MP
Image ProcessorTruePic X
ConnectivityWi-Fi, Bluetooth, USB-C, HDMI
Body ConstructionMagnesium Alloy
Dimensions134.8 x 91.6 x 72.7 mm
Sensor SizeFour Thirds
ISO RangeISO 200-102400 (expandable to ISO 80-102400)
Image Stabilization5-axis in-body
Autofocus System1053-Point Hybrid Autofocus
Viewfinder TypeElectronic (EVF)
Viewfinder Resolution5.76 million dots
Viewfinder Magnification1.65x (35mm equivalent)
Rear Screen3.0" vari-angle touchscreen
Rear Screen Resolution1.62 million dots
Video Recording4K UHD at 60p/50p/30p/25p/24p
Video FormatMOV
Audio RecordingStereo, external mic input
Storage MediaDual SD Card Slots (UHS-II)
BatteryBLX-1 Lithium-Ion Battery
Weight599 g (with battery and memory card)
Battery LifeApprox. 520 shots (CIPA standard)
Shutter Speed1/8000 to 60 sec
Weather SealingYes (IP53 rated)
