Select a function with which you want to save different settings
for landscape and portrait orientations, and put a check (P)
next to it.
Select an option using FG and press the OK button to
put a check (P) next to it.
To remove the check, press the OK button again.
K
Orientation Linked
Y
MENU
OK
AF Target Point
AF Target Mode
KOrientation Linked Y
setting screen
Functions for setting the focusing
position
Matching AF Target Selection to Camera
Orientation (KOrientation Linked Y)
P A S M B n
The camera can be configured to change the AF target position and AF target mode automatically
when it detects that it has been rotated between landscape (wide) or portrait (tall) orientations.
Rotating the camera changes the composition and consequently also the position of the subject in
the frame. The camera can store the AF target mode and AF target position separately according
to camera orientation. When this option is active, [KY Set Home] (P.138) can be used to store
separate home positions for landscape and portrait orientations.
Menu
MENU U AF U 6. AF Target Settings & Operations U KOrientation Linked Y
AF Target
Mode
When you put a check (P) next to this, the camera saves separate
AF target modes (e.g., bAll, oSmall) for landscape and portrait
orientations.
AF Target
Point
When you put a check (P) next to this, the camera saves separate AF
target positions for landscape and portrait orientations.
136
Matching AF Target Selection to Camera
Orientation (KOrientation Linked Y)
1.

Table of Contents

Other manuals for OM SYSTEM OM-1 Mark II

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the OM SYSTEM OM-1 Mark II and is the answer not in the manual?

OM SYSTEM OM-1 Mark II Specifications

General IconGeneral
Camera TypeMirrorless
Sensor Resolution20.4MP
Image ProcessorTruePic X
ConnectivityWi-Fi, Bluetooth, USB-C, HDMI
Body ConstructionMagnesium Alloy
Dimensions134.8 x 91.6 x 72.7 mm
Sensor SizeFour Thirds
ISO RangeISO 200-102400 (expandable to ISO 80-102400)
Image Stabilization5-axis in-body
Autofocus System1053-Point Hybrid Autofocus
Viewfinder TypeElectronic (EVF)
Viewfinder Resolution5.76 million dots
Viewfinder Magnification1.65x (35mm equivalent)
Rear Screen3.0" vari-angle touchscreen
Rear Screen Resolution1.62 million dots
Video Recording4K UHD at 60p/50p/30p/25p/24p
Video FormatMOV
Audio RecordingStereo, external mic input
Storage MediaDual SD Card Slots (UHS-II)
BatteryBLX-1 Lithium-Ion Battery
Weight599 g (with battery and memory card)
Battery LifeApprox. 520 shots (CIPA standard)
Shutter Speed1/8000 to 60 sec
Weather SealingYes (IP53 rated)
