One-touch white balance
Measure white balance by framing a piece of paper or other white object under the lighting that will
be used in the final photograph. Use this option to fine-tune white balance when you find it hard to
obtain the desired results with white balance compensation or preset white balance options such as
A (sunlight) or D (overcast). The camera stores the metered value for quick recall as required.
Settings for still photography and movie recording can be stored individually.
Select [H], [I], [J], or [K] (one-touch white balance 1, 2, 3, or 4) on the WB setting
screen.
Select GSet.
Frame a piece of colorless (white or gray) paper in the center of the display.
Frame the piece of paper so that it fills the display. Ensure that it is free of shadows.
Press the INFO button.
The one-touch white balance screen appears.
Highlight [Yes] and press the OK button.
The new value is saved as a preset white balance option.
The new value is stored until one-touch white balance is measured again. Turning the power
off does not erase the data.
Metering White Balance with the One-Touch White Balance
Button (V)
Assigning [G] to a button allows the control to be used to measure white balance. By default, the
V button can be used to measure white balance during still photography. To measure white balance
during movie recording, you must first assign one-touch white balance to a control using [nButton
Function] (P.334).
Frame a piece of colorless (white or gray) paper in the center of the display.
Frame the piece of paper so that it fills the display. Ensure that it is free of shadows.
231
Adjusting color (WB (white balance))
1.
2.
3.
4.
1.

Table of Contents

Other manuals for OM SYSTEM OM-1 Mark II

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the OM SYSTEM OM-1 Mark II and is the answer not in the manual?

OM SYSTEM OM-1 Mark II Specifications

General IconGeneral
Camera TypeMirrorless
Sensor Resolution20.4MP
Image ProcessorTruePic X
ConnectivityWi-Fi, Bluetooth, USB-C, HDMI
Body ConstructionMagnesium Alloy
Dimensions134.8 x 91.6 x 72.7 mm
Sensor SizeFour Thirds
ISO RangeISO 200-102400 (expandable to ISO 80-102400)
Image Stabilization5-axis in-body
Autofocus System1053-Point Hybrid Autofocus
Viewfinder TypeElectronic (EVF)
Viewfinder Resolution5.76 million dots
Viewfinder Magnification1.65x (35mm equivalent)
Rear Screen3.0" vari-angle touchscreen
Rear Screen Resolution1.62 million dots
Video Recording4K UHD at 60p/50p/30p/25p/24p
Video FormatMOV
Audio RecordingStereo, external mic input
Storage MediaDual SD Card Slots (UHS-II)
BatteryBLX-1 Lithium-Ion Battery
Weight599 g (with battery and memory card)
Battery LifeApprox. 520 shots (CIPA standard)
Shutter Speed1/8000 to 60 sec
Weather SealingYes (IP53 rated)
