OM SYSTEM OM-1 Mark II User Manual

Specifying a folder to save images in (Assign
Save Folder)
P A S M B n
Specify the folder on the card in which the images will be saved.
Menu
MENU U e U 1. Card/Folder/File U Assign Save Folder
Assign
1
[New Folder]: Specify a 3-digit folder number.
1st digit: [0] – [9]
2nd digit: [0] – [9]
3rd digit: [0] – [9]
[Existing Folder]: Select an existing folder using FG. The first two frames and the
last frame in the folder are displayed.
Do not
assign
The folder in which the images will be saved is not specified. If a folder has already
been specified, selection will be cancelled.
If a folder has already been specified, the name of the folder is displayed. To select a different
folder, press I.
391
Specifying a folder to save images in (Assign
Save Folder)
1

OM SYSTEM OM-1 Mark II Specifications

General

Camera Type	Mirrorless
Sensor Resolution	20.4MP
Image Processor	TruePic X
Connectivity	Wi-Fi, Bluetooth, USB-C, HDMI
Body Construction	Magnesium Alloy
Dimensions	134.8 x 91.6 x 72.7 mm
Sensor Size	Four Thirds
ISO Range	ISO 200-102400 (expandable to ISO 80-102400)
Image Stabilization	5-axis in-body
Autofocus System	1053-Point Hybrid Autofocus
Viewfinder Type	Electronic (EVF)
Viewfinder Resolution	5.76 million dots
Viewfinder Magnification	1.65x (35mm equivalent)
Rear Screen	3.0" vari-angle touchscreen
Rear Screen Resolution	1.62 million dots
Video Recording	4K UHD at 60p/50p/30p/25p/24p
Video Format	MOV
Audio Recording	Stereo, external mic input
Storage Media	Dual SD Card Slots (UHS-II)
Battery	BLX-1 Lithium-Ion Battery
Weight	599 g (with battery and memory card)
Battery Life	Approx. 520 shots (CIPA standard)
Shutter Speed	1/8000 to 60 sec
Weather Sealing	Yes (IP53 rated)
