Configure options.
Press FG to select an item and press the OK button to
display the setting menu.
Press the OK button again to return to the KAF Focus
Adjustment setting screen.
MENU OK
±0
On
K
AF Focus Adjustment
AF Focus Adjustment
Fine-tuning Value
Configuring [AF Focus Adjustment]
Fine-tuning Value
Adjusts focus for all lenses. Focus can be fine-tuned by up to ±20 steps.
[-20] – [±0] – [+20]
You can zoom in on the display by using the front dial or R button to check the results.
You can take a test picture to check the results by pressing the shutter button before pressing the
OK button.
133
Fine-Tuning Autofocus (KAF Focus Adjustment)
1.
B
B

OM SYSTEM OM-1 Mark II Specifications

General

Camera Type	Mirrorless
Sensor Resolution	20.4MP
Image Processor	TruePic X
Connectivity	Wi-Fi, Bluetooth, USB-C, HDMI
Body Construction	Magnesium Alloy
Dimensions	134.8 x 91.6 x 72.7 mm
Sensor Size	Four Thirds
ISO Range	ISO 200-102400 (expandable to ISO 80-102400)
Image Stabilization	5-axis in-body
Autofocus System	1053-Point Hybrid Autofocus
Viewfinder Type	Electronic (EVF)
Viewfinder Resolution	5.76 million dots
Viewfinder Magnification	1.65x (35mm equivalent)
Rear Screen	3.0" vari-angle touchscreen
Rear Screen Resolution	1.62 million dots
Video Recording	4K UHD at 60p/50p/30p/25p/24p
Video Format	MOV
Audio Recording	Stereo, external mic input
Storage Media	Dual SD Card Slots (UHS-II)
Battery	BLX-1 Lithium-Ion Battery
Weight	599 g (with battery and memory card)
Battery Life	Approx. 520 shots (CIPA standard)
Shutter Speed	1/8000 to 60 sec
Weather Sealing	Yes (IP53 rated)
